3-way wall speaker, power 80W
The CWM8.3 D is a three-way in-wall speaker. It features a 25mm diamond dome tweeter, 130mm FST Continuum midrange and two 180mm Aerofoil woofers. The rotating central basket allows you to use the CWM8.3 both vertically and horizontally.
The CWM8.3 D is designed to offer performance for those who want an impeccable yet unobtrusive sound. This three-way model features a 25mm diamond dome tweeter, 130mm FST Continuum midrange and two 180mm Aerofoil woofers.
The most precise high-frequency transducer in its category and a rigid and light diamond diaphragm allow high frequencies to be reproduced perfectly and without distortion. The CWM8.3 D also includes an FST Continuum woofer/midrange driver for flawless low- and mid-frequency sounds. A prestigious feature of the only three-way loudspeaker in the range is the presence of super-light and ultra-rigid Aerofoil woofers for impeccable bass reproduction.
The rear box of the CWM8.3 D is made entirely in Matrix™, to ensure maximum rigidity and exceptional performance. The rear box also has a series of double-ended connectable cables routed up to the terminal block through special conduits and connected to the cage with a multi-pin connector. The CWM8.3 D has also been developed to fit existing rear boxes, therefore allowing owners of the original CWM8.3 to upgrade quickly and easily.
Model |
CWM8.3D |
Description |
Three-way wall speaker |
Technical features |
Mini aluminum basket that can be rotated by 90 degrees Nautilus™ tweeter with diamond dome and duct load Anti-resonance protection Flowport™ Midrange FST™ Aerofoil woofer with carbon reinforcement |
Transducers |
1 x 25 mm ø Nautilus™ diamond dome tweeter with tube loading 1 x 130 mm ø Continuum midrange 2 x 180 mm ø Aerofoil woofers |
Frequency Range (-6dB) |
30Hz - 35kHz |
Recommended amplifier power |
200W |
Sensitivity |
89dB |
nominal impedance |
8 ohms |
Frame height |
880mm |
Frame width |
254mm |
Recessed hole height |
864mm |
Cutout width |
238mm |
Ledge from the wall |
8mm |
Net weight |
10.9kg |
Rear box |
BB CWM8.3 |
