Focal 100 ICW5 T

Focal 100 ICW5 T: 2-way in-wall and in-ceiling loudspeaker with transformer

The version of the 100 ICW5 for constant-voltage systems: the built-in adjustable transformer connects it to a 70 or 100 V line, with several loudspeakers in a chain, as is done in hotels, restaurants and other spaces open to the public. Few amplifier channels serve a large listening area, with the same quality as the low-impedance model.

The Polyglass membrane, a Focal exclusive, is a cellulose cone coated with glass microbeads: the stiffness of glass adds to the damping of paper, for a clean, uncoloured midrange. The treble is handled by an aluminium inverted-dome tweeter, a Focal signature since 1981, which gives wide dispersion and very low directivity.

Installation

Shallow mounting depth, optimised fixing brackets and a one-piece frame: installation is quick. The magnetic grille is ready to be painted in the colour of the wall or ceiling. 157 mm cut-out and 100 mm depth.

• Frequency response (±3 dB): 65 Hz - 23 kHz
• Low frequency point (-6 dB): 56 Hz
• Sensitivity 88 dB
• Mounting depth 100 mm, cut-out 157 mm in diameter, for panels from 8 to 35 mm
• Built-in transformer for 70 V / 100 V line
• Paintable magnetic grille, cutting template supplied
