MM phono detector
--
Spherical stylus. Output voltage 4mV (mono). Recommended reading weight 1,8gr. Recommended load resistance 47Kohm. Weight 7,2gr.;"
Output voltage at 1000Hz, 5cm/sec.;4mV
Channel balance at 1kHz;-
Channel separation at 1 kHz;-
Channel separation at 15 kHz;-
Frequency range at - 3dB; 20-20,000Hz
Frequency response; 20-20,000Hz + 3 / - 1dB
Tracking ability at 315Hz at recommended tracking force;70µm
Compliance, dynamic, lateral; 18 µm/mN
Stylus type; Spherical
Stylus tip radius;R 65 µm
Tracking force range;1.6-2.0g (16-20mN)
Tracking force, recommended; 1.8 g (18 mN)
Tracking angle;20°
Internal impedance, DC resistance; 700 ohms
Internal inductance; 300mH
Recommended load resistance; 47 kOhm
Recommended load capacitance;150-300pF
Cartridge colour, body/stylus;Black/Grey
Cartridge weight without screws;7,2 g"
2M 78 VERSE:
Same as 2M 78, but with screw mounts designed for bottom mount cartridge arms.
