Motorised TV lift with horizontal movement
LSM-HZ is a Future Automation mechanism that slides the screen sideways to its viewing position and afterwards draws it back in fully, where it can no longer be seen.
It suits installations where neither floor nor ceiling space can be used: the screen may come out, for instance, from beside a fireplace, from a recess in the wall or from a bespoke cabinet. A fixed panel (lid) is attached at the front and finished like the wall or the cabinetry, hiding the opening while the mechanism is closed.
Key features
- Motorised horizontal movement
- Load up to 50 kg, or 30 kg in marine use
- VESA mounting patterns from 200 to 400 mm, in width and in height
- Complete cable management
- Declared noise level 52 dB
- IR remote control in the box
- Options: dedicated mounts and adapters for Loewe and B&O, custom RAL colours
Available sizes
The model is chosen by the width of the screen. LSM-HZ-FP5 takes screens up to 1265 mm wide and needs an internal cabinet width of 1690 mm; LSM-HZ-FP6 takes screens up to 1490 mm wide and needs 1910 mm.
Control and integration
The lift comes with contact closure, IR and RS232 control, and an RF version exists. The supply required is 110-240 V AC. A sound bar can be fitted below the screen using the USM speaker mount.
Environments
LSM-HZ is for indoor use and is marine suitable, indoors only; its robust beam is suited to marine installation.
