2-way floorstanding loudspeaker with a 250 mm IsoFlare driver
Vintage Classic X is a 2-way floorstanding loudspeaker from the Vintage Classic range, with a high-volume cabinet and retro-inspired styling. It is meant for listeners who like the look of 1970s loudspeakers and expect present-day performance. Sold as a pair.
The rectangular cabinet has panels veneered in real wood, gold trim and a black baffle whose size keeps a traditional proportion to the driver diameter. The structure is high-density fibreboard with a walnut veneer, braced internally. The 250 mm IsoFlare point source unit pairs a multi-fibre cone for bass and midrange with a compression tweeter using a 75 mm titanium alloy dome; the magnet is a ferrite type. The reflex port fires downwards and works with the BassTrax Tractrix diffuser.
Key features
- 2-way system with a port firing towards the floor and BassTrax Tractrix diffuser
- 250 mm IsoFlare point source unit with a 75 mm compression tweeter in titanium alloy
- Frequency response of 28 Hz - 26 kHz (-6 dB, typical in room)
- Sensitivity of 94 dB (2.83 V at 1 m), nominal impedance of 8 ohm
- Suggested amplifier output from 20 to 280 watt RMS; 140 watt RMS continuous, 560 watt peak
- Low-loss passive crossover, ready for bi-wiring, with Cryo-Lite treatment
- ±3 dB adjustments for high-frequency energy and for presence
Technical data
The crossover operates at 750 Hz, using second-order filters on both the low-pass and the high-pass side. The presence adjustment acts between 2.5 and 5 kHz. The cabinet measures 918 x 450 x 381 mm (height x width x depth) and weighs 45.2 kg: size and weight apply to one loudspeaker. For anyone adding a super tweeter, the data sheet gives its distance from the cabinet's front edge: 106 mm for S-Trax, 82 mm for SuperTrax.
Finishes
The loudspeaker is offered in the Walnut finish, with a black baffle and gold trim.
