MM/MC phono stage
--
MM/MC phono stage with 16 different settings via micro switch. Separate PWX power supply stage. Selected Components;"
Sensitivity for output level 775 mV/ 0 dB (with activated high gain switch)
Gain 1kHz
Maximum input level 1kHz
Signal to noise ratio (RMS unweighted);MM: 3.8mV/1kHz; MC: 0.38mV/1kHz
MM: 46dB; MC: 66dB
MM: 45mV; MC: 4.5mV
MM: 71dB; MC: 63dB
Gain;36dB, 46dB, 56dB, 66dB
Channel separation; >80dB at 10kHz
Input impedance;47 kohms, 1 kohm, 100 ohms
1 x custom load
1 x hardwire slot
Output impedance;47 ohms
Input capacitance;100pF
Channel mismatch; typ. 0.5dB
Bass filter;16 settings between 7Hz and app. 90Hz
Power consumption;< 3W
Outer dimensions W x D x H;Audio section: 114 mm x 124 mm 50 mm
PWX power supply: 93mm x 233mm x 45mm
Weight;Audio section: 0.6 kg net
PWX power supply: 1.0 kg net"
